Product Description
Legend: S = Standard AO = Additional Option N/A = Not Applicable
| Performance | Dell Wyse R10L | Dell Wyse R50L | Dell Wyse R90L7 | Dell Wyse R90LW |
| Operating System | Dell Wyse ThinOS™ | Dell Wyse-enhanced SUSE Linux | Windows Embedded Standard 7 | Windows Embedded Standard 2009 |
| Processor | 1.5GHz AMD Sempron | 1.5GHz AMD Sempron | 1.5GHz AMD Sempron | 1.5GHz AMD Sempron |
| Memory | 128MB Flash / 512MB RAM | 1GB Flash / 1GB RAM | 4GB Flash / 2GB RAM | Standard: 2GB Flash / 1GB RAM, Maximum 4GB Flash / 2GB RAM |
| Graphics | AMD ATI 690E | AMD ATI 690E | AMD ATI 690E | AMD ATI 690E |
| Power | Worldwide auto-sensing 100-240 VAC, 50/60 Hz 65W, 19V DC | Worldwide auto-sensing 100-240 VAC, 50/60 Hz 65W, 19V DC | Worldwide auto-sensing 100-240 VAC, 50/60 Hz 65W, 19V DC | Worldwide auto-sensing 100-240 VAC, 50/60 Hz 65W, 19V DC |
| Power consumption | 14.6 Watts (average) | 14.6 Watts (average) | 14.6 Watts (average) | 14.6 Watts (average) |
| Security | Built-in Kensington security slot (cable sold separately) | Built-in Kensington security slot (cable sold separately) | Built-in Kensington security slot (cable sold separately) | Built-in Kensington security slot (cable sold separately) |
| I/O peripheral support | Dell Wyse R10L | Dell Wyse R50L | Dell Wyse R90L7 | Dell Wyse R90LW |
| One DVI-I port, DVI to VGA (DB-15) adapter included | S | S | S | S |
| One DVI-D port | S | S | S | S |
| Two PS/2 ports | S | S | S | S |
| Two serial ports | S | S | S | S |
| Six external USB 2.0 ports (2 front; 4 back) | S | S | S | S |
| Four internal USB 2.0 ports | N/A | N/A | S | N/A |
| One mic in | N/A | N/A | S | N/A |
| One line out | N/A | N/A | S | N/A |
| One parallel port | N/A | N/A | S | N/A |
| Networking | Dell Wyse R10L | Dell Wyse R50L | Dell Wyse R90L7 | Dell Wyse R90LW |
| 10/100/1000 Base-T Gigabit Ethernet | 10/100/1000 Base-T Gigabit Ethernet | 10/100/1000 Base-T Gigabit Ethernet | 10/100/1000 Base-T Gigabit Ethernet | |
| Optional internal wireless 802.11 b/g | Optional internal wireless 802.11 b/g/n | Optional internal wireless 802.11 b/g/n | Optional internal wireless 802.11 b/g/n | |
| Display | Dell Wyse R10L | Dell Wyse R50L | Dell Wyse R90L7 | Dell Wyse R90LW |
| VESA monitor support with Display Data Control (DDC) for automatic setting of resolution and refresh rate | S | S | S | S |
| Single Monitor | 2560 x 1600 32 bpp 60Hz | 1920X1200@60Hz; color depth: 32 bpp | 2560X1600@60Hz; color depth: 32 bpp | 2560X1600@60Hz; color depth: 32 bpp |
| Dual Monitor | 1920 x 1200 32 bpp 60Hz | 1920X1200@60Hz; color depth: 32 bpp | 2560X1600@60Hz; color depth: 16 bpp | 2560X1600@60Hz; color depth: 16 bpp |
| Two independent full resolution frame buffers | S | S | S | S |
| Audio | Dell Wyse R10L | Dell Wyse R50L | Dell Wyse R90L7 | Dell Wyse R90LW |
| Output: 1/8-inch mini jack, full 16-bit stereo, 48KHz sample rate. | S | S | S | S |
| Input: 1/8-inch mini jack, 8-bit microphone | S | S | S | S |
| Internal mono speaker | S | S | S | S |
| Dimensions | Dell Wyse R10L | Dell Wyse R50L | Dell Wyse R90L7 | Dell Wyse R90LW |
| Height x Width x Depth | 250 mm x 225 mm x 53 mm (9.8 inches x 8.8 inches x 2.1 inches) | 250 mm x 225 mm x 53 mm (9.8 inches x 8.8 inches x 2.1 inches) | 250 mm x 225 mm x 53 mm (9.8 inches x 8.8 inches x 2.1 inches) | 250 mm x 225 mm x 53 mm (9.8 inches x 8.8 inches x 2.1 inches) |
| Weight | 1.850 kg (4.08 lbs) | 1.850 kg (4.08 lbs) | 1.850 kg (4.08 lbs) | 1.850 kg (4.08 lbs) |
| Mountings | Dell Wyse R10L | Dell Wyse R50L | Dell Wyse R90L7 | Dell Wyse R90LW |
| Vertical stand | S | S | S | S |
| Horizontal stand | AO | AO | AO | AO |
| Wall mounting bracket | AO | AO | AO | AO |
| Temperature Range | Dell Wyse R10L | Dell Wyse R50L | Dell Wyse R90L7 | Dell Wyse R90LW |
| Horizontal position | 10° to 35° C (50° to 95° F) | 10° to 35° C (50° to 95° F) | 10° to 35° C (50° to 95° F) | 10° to 35° C (50° to 95° F) |
| Vertical position, power button up | 10° to 40° C (50° to 104° F) | 10° to 40° C (50° to 104° F) | 10° to 40° C (50° to 104° F) | 10° to 40° C (50° to 104° F) |
| Storage | -10° to 60° C (14° to 140° F) | -10° to 60° C (14° to 140° F) | -10° to 60° C (14° to 140° F) | -10° to 60° C (14° to 140° F) |
| Humidity | Dell Wyse R10L | Dell Wyse R50L | Dell Wyse R90L7 | Dell Wyse R90LW |
| Condensing | 20% to 80% | 20% to 80% | 20% to 80% | 20% to 80% |
| Non-condensing | 10% to 95% | 10% to 95% | 10% to 95% | 10% to 95% |
| Included | Dell Wyse R10L | Dell Wyse R50L | Dell Wyse R90L7 | Dell Wyse R90LW |
| Enhanced PS/2 keyboard with Windows Keys (104 keys) & PS/2 optical mouse included | S | S | S | S |
| Warranty | Dell Wyse R10L | Dell Wyse R50L | Dell Wyse R90L7 | Dell Wyse R90LW |
| 3-year limited hardware warranty | S | S | S | S |
